1000-20000LPH RO Water Treatment Plant

Details

We offer a one-stop service for water treatment system design, production, and installation. We can customize water treatment systems according to customers' usage requirements, meeting various production needs ranging from 1000 LPH to 400000 LPH.

Technical Parameters:

Model	Capacity	Operation	Feed inlet	Membrane	Membrane	Desalination	Recovery	Power
Model	(T/H)	(MPa)	(MM)	Size(Inch)	(Qty)	Desalination	Recovery	(KW)
FRRO-0.25T	0.25	1.0-1.4	DN20	40×40	1	≥97%	60-80%	2
FRRO-0.5T	0.5	1.0-1.4	DN20	40×40	2	≥97%	60-80%	2.5
FRRO-0.75T	0.75	1.0-1.4	DN25	40×40	3	≥97%	60-80%	3
FRRO-1	1	1.0-1.4	DN25	40×40	4	≥97%	60-80%	3.3
FRRO-2	2	1.0-1.4	DN25	40×40	8	≥97%	60-80%	4.5
FRRO-3	3	1.0-1.4	DN32	40×40	12	≥97%	60-80%	8
FRRO-5	5	1.0-1.4	DN40	80×40	5	≥97%	60-80%	16
FRRO-10	10	1.0-1.4	DN50	80×40	10	≥97%	60-80%	22
FRRO-15	15	1.0-1.4	DN50	80×40	15	≥97%	60-80%	32
FRRO-20	20	1.0-1.4	DN65	80×40	20	≥97%	60-80%	42
FRRO-30	30	1.0-1.4	DN80	80×40	30	≥97%	60-80%	55
FRRO-40	40	1.0-1.4	DN100	80×40	40	≥97%	60-80%	65
FRRO-50	50	1.0-1.4	DN125	80×40	50	≥97%	60-80%	65

Working process:

Raw water pump → Mechanical filter (quartz sand filter) → Activated carbon filter → Water softener (anti-scaling and chemical dosing system) → Safety filter → High-pressure pump → Reverse osmosis → Water tank → High-pressure pump → Reverse osmosis

RO system achieves a filtration precision of up to 0.001 microns, effectively separating all soluble salts, colloids, organic matter, microorganisms, viruses, bacteria, rust, and heavy metal particles from water. This process uses pressure to force pure water through a membrane, trapping impurities on the membrane to purify the water. 1000-20000LPH RO Water Treatment Plant can be customized to meet specific application requirements.

Why choose Foren?

We have our own factory, a professional R&D team, and experienced operators.

FOREN factory is located in Qingzhou City, Weifang City, Shandong Province, China. Since 2014, we have been specializing in the development and production of water treatment equipment, serving over 500 clients and enjoying an excellent reputation.
